GIGABYTE B760M DS3H WIFI6E GEN5 Intel B760 DDR5 Motherboard

Intel B760 DDR5 Motherboard with PCIe 5.0 and WiFi 6E

The GIGABYTE B760M DS3H WIFI6E GEN5 is a Micro ATX motherboard designed for compatible Intel Core 12th, 13th and 14th Generation processors. Based on the Intel B760 chipset, it combines DDR5 memory, PCIe 5.0 graphics expansion, PCIe 4.0 NVMe storage and high-speed wired and wireless networking for modern desktop PC builds.

Featuring a Hybrid 6+2+1 phase VRM solution, four DDR5 DIMM slots, dual PCIe 4.0 x4 M.2 connectors, 2.5GbE LAN and WiFi 6E, the motherboard provides a balanced platform for gaming, productivity, content creation and everyday high-performance computing.

Product Features

Intel LGA1700 Platform: Supports compatible Intel Core 12th, 13th and 14th Generation processors using the LGA1700 socket.

Intel B760 Chipset: The B760 chipset provides a modern Intel desktop platform with support for DDR5 memory, high-speed PCIe connectivity and NVMe storage.

Hybrid 6+2+1 Phase VRM: The Hybrid 6+2+1 phase VRM solution provides stable power delivery for compatible Intel processors and system components.

Four DDR5 DIMM Slots: Four DDR5 DIMM slots provide dual-channel memory support with flexible capacity and upgrade options.

DDR5 Up to 7600MHz (OC): Support for high-speed DDR5 memory configurations up to 7600MHz (OC) provides additional memory bandwidth with compatible hardware.

Intel XMP Support: Compatible XMP memory modules can use supported memory profiles for convenient configuration of higher DDR5 speeds.

PCIe 5.0 x16: The primary PCIe 5.0 x16 slot provides high-bandwidth connectivity for compatible graphics cards.

PCIe UD Slot: The SMD PCIe 5.0 slot incorporates reinforced construction to provide enhanced physical support for compatible graphics cards.

EZ-Latch: The PCIe x16 slot includes GIGABYTE EZ-Latch technology for easier graphics card release during maintenance and upgrades.

Dual PCIe 4.0 M.2: Two PCIe 4.0 x4 M.2 connectors provide high-speed storage connectivity for compatible NVMe solid-state drives.

2.5GbE LAN: Integrated 2.5 Gigabit Ethernet provides high-speed wired networking when connected to compatible network equipment.

WiFi 6E: Integrated WiFi 6E provides high-speed wireless connectivity with compatible routers and wireless networks.

WIFI EZ-Plug: GIGABYTE’s WIFI EZ-Plug design simplifies connection and installation of the supplied wireless antenna.

WIFI Compass: WIFI Compass helps identify an effective antenna position for improved wireless signal reception.

Rear USB-C 10Gb/s: Rear USB Type-C connectivity provides data transfer speeds up to 10Gb/s with compatible devices.

HDMI and DisplayPort: HDMI and DisplayPort provide digital display connectivity when used with a compatible Intel processor featuring integrated graphics.

Smart Fan 6: Smart Fan 6 combines multiple temperature sensors and hybrid fan headers for flexible system cooling management.

FAN STOP: Compatible fans can be configured to stop under suitable temperature conditions to help reduce unnecessary system noise.

Q-Flash Plus: Q-Flash Plus enables supported BIOS updates without requiring the processor, memory or graphics card to be installed.

Product Specifications

*Processor compatibility and achievable DDR5 memory speeds depend on the motherboard revision, installed BIOS version, processor, memory modules and system configuration.

Intel 12th, 13th and 14th Gen Processor Support

The GIGABYTE B760M DS3H WIFI6E GEN5 supports compatible Intel Core 12th, 13th and 14th Generation processors on the LGA1700 platform. This provides flexibility when building or upgrading an Intel-based desktop PC.

DDR5 Memory Up to 7600MHz (OC)

Four DDR5 DIMM slots provide dual-channel memory support with speeds up to 7600MHz (OC) under compatible configurations. Intel XMP support makes it easier to configure supported performance memory profiles.

PCIe 5.0 Graphics Expansion

The primary PCIe 5.0 x16 slot provides high-bandwidth connectivity for compatible graphics cards. The PCIe UD Slot design adds physical reinforcement, while EZ-Latch simplifies graphics card removal.

Dual PCIe 4.0 x4 M.2 Storage

Two PCIe 4.0 x4 M.2 connectors provide high-speed storage expansion for compatible NVMe SSDs, helping improve operating system responsiveness, application loading and large file transfers.

WiFi 6E Wireless Connectivity

Integrated WiFi 6E provides fast wireless networking with compatible equipment. WIFI EZ-Plug simplifies antenna installation, while WIFI Compass helps users identify a suitable antenna position for wireless reception.

2.5 Gigabit Ethernet

Integrated 2.5GbE LAN provides higher wired network bandwidth than conventional Gigabit Ethernet when connected to compatible networking hardware, making it useful for gaming, high-speed downloads and local file transfers.

Rear USB-C 10Gb/s Connectivity

A rear USB Type-C interface supporting up to 10Gb/s provides high-speed connectivity for compatible external SSDs, storage devices and other USB-C peripherals.

Smart Fan 6 Cooling

Smart Fan 6 uses multiple temperature sensors and hybrid fan headers to provide flexible system cooling management. FAN STOP functionality can stop compatible fans under suitable operating conditions to help reduce system noise.

Q-Flash Plus BIOS Update

GIGABYTE Q-Flash Plus allows supported BIOS updates without installing the CPU, memory or graphics card. This can be useful when preparing the motherboard for a processor that requires a newer BIOS version.

Important Compatibility Information

Before purchasing, confirm compatibility between the intended Intel processor, motherboard revision and installed BIOS version. Some processors may require an appropriate BIOS update.

DDR5-7600 is an overclocked memory specification. Achievable memory speed depends on the processor’s memory controller, DIMM configuration, memory modules and BIOS settings.

Motherboard HDMI and DisplayPort outputs require a compatible Intel processor with integrated graphics.
