KODAK i4650 A3 Production Scanner 150ppm 300ipm 500-Sheet ADF USB 3.2
- 150ppm / 300ipm High-Speed Duplex Scanning with Up to 130,000 Pages Daily Volume
- 500-Sheet ADF with SurePath Intelligent Document Feed Technology
- Interactive Multifeed Recovery with Document Protection and Metal Detection
- 600dpi Resolution, USB 3.2 and Digital and Physical Imprinting Options
KODAK i4650 A3 Production Scanner 150ppm 300ipm 500-Sheet ADF USB 3.2
Product Features
The KODAK i4650 is a compact A3 production document scanner designed for high-volume scanning environments requiring fast throughput, reliable document feeding and advanced image processing. It is suitable for government departments, financial institutions, service bureaus and centralized document-processing operations.
The scanner delivers throughput speeds of up to 150 pages per minute and 300 images per minute. Its recommended daily volume of up to 130,000 pages supports demanding production workflows where substantial document batches must be processed regularly.
A 500-sheet automatic document feeder enables large batches to be scanned with fewer paper-loading interruptions. The scanner supports paper weights ranging from 45 to 200 g/m² and documents measuring from 50.8 × 63.5 mm up to 305 mm wide and 9.1 metres long.
Documents can exit through the front output tray or through the rear when the straight-through paper path is manually selected. The rear exit provides a flatter paper route for long documents and media requiring more controlled handling.
SurePath intelligent document feed technology combines controlled stacking, enhanced jam recovery, Intelligent Document Protection, interactive multifeed recovery, length-based multifeed detection, ultrasonic multifeed technology and metal detection.
Interactive Multifeed Recovery allows operators to review potential multifeeds and choose whether to accept, ignore or rescan an image before it is sent to the connected application. This can reduce unnecessary rescanning and batch interruptions.
Intelligent Document Protection monitors paper movement to help prevent document damage. Metal detection identifies staples, paper clips and other metallic objects that could damage original documents or interrupt the scanning process.
The KODAK i4650 uses dual white LED illumination with CCD scanning technology. It provides a maximum optical and output resolution of 600dpi, with 256-level 8-bit grayscale output, 24-bit colour output and 48-bit colour capture.
Perfect Page image-enhancement features include adaptive threshold processing, automatic cropping, deskew, automatic colour detection, blank-page removal, image merging, sharpening, streak filtering and electronic colour dropout.
A 3.5-inch graphical colour LCD provides access to scanning functions and operator information. Operator overrides help users manage document exceptions without unnecessarily stopping the complete scanning batch.
The scanner supports digital and physical imprinting options for workflows requiring identification, tracking or reference information. Supported barcode formats can also assist with document separation, classification and indexing.
USB 3.2 Gen 1×1 connectivity provides a direct connection to a compatible workstation. Driver support includes ISIS, TWAIN, WIA and Linux TWAIN and SANE, along with KOFAX certification.
Optional KODAK Capture Pro Software and Info Input Solution can be added for expanded document capture and information-processing requirements. Scanned data is processed exclusively through volatile memory and effectively erased when the scanner is shut down.
Technical Specifications
| Brand | KODAK |
| Model | i4650 |
| Product Type | Compact High-Volume A3 Production Scanner |
| Scanning Speed | Up to 150 ppm / 300 ipm |
| Recommended Daily Volume | Up to 130,000 Pages per Day |
| Feeder Capacity | Up to 500 Sheets of 80 g/m² Paper |
| Maximum Document Size | 305 × 9,100 mm (12 × 360 Inches) |
| Minimum Document Size | 50.8 × 63.5 mm (2 × 2.5 Inches) |
| Supported Paper Weight | 45–200 g/m² (12–110 lb.) |
| Paper Path Options | Front Output Tray or Manually Selected Rear Straight-Through Path |
| Feed Technology | SurePath Intelligent Document Feed Technology |
| Stacking | Controlled Stacking |
| Jam Recovery | Enhanced Jam Recovery |
| Document Protection | Intelligent Document Protection |
| Multifeed Handling | Interactive Multifeed Recovery |
| Multifeed Detection | Length and Ultrasonic Multifeed Detection |
| Metal Detection | Staple, Paper Clip and Metal Detection |
| Operator Overrides | Supported |
| Imprinting | Digital and Physical Imprinting Options |
| Maximum Optical Resolution | 600 dpi |
| Maximum Image Output Resolution | Up to 600 dpi |
| Scanning Technology | Dual White LED Illumination CCD |
| Grayscale Output | 256 Levels, 8-Bit |
| Colour Output | 24-Bit Colour Output |
| Colour Capture | 48-Bit Colour Capture |
| Image Enhancement | Adaptive Threshold Processing, Autocrop, Deskew, Automatic Colour Detection, Blank-Page Removal, Image Merge, Sharpening, Streak Filtering and Electronic Colour Dropout |
| Connectivity | USB 3.2 Gen 1×1 Certified |
| Operator Control Panel | 3.5-Inch Graphical Colour LCD |
| Standard Drivers | ISIS, TWAIN and WIA |
| Linux Support | Linux TWAIN and SANE |
| Certification | KOFAX Certified |
| Optional Software | KODAK Capture Pro Software and Info Input Solution |
| File Formats | BMP, JPEG, PDF, PNG, Multipage TIFF, Single-Page TIFF, Searchable PDF, Microsoft Excel, Microsoft Word and RTF |
| Supported Barcodes | Codabar, Code 128, Code 3 of 9, EAN-13, EAN-8, Interleaved 2 of 5, PDF417, QR, UPC-A and UPC-E |
| Supported Windows Systems | Windows 10, Windows 11 and Windows Server 2012–2022 |
| Supported Linux Systems | NeoKylin Linux, OpenSUSE, SUSE Linux Enterprise Desktop, Ubuntu 18.04 and Ubuntu 20.04 |
| Data Security | Volatile Memory Processing Erases Scanned Image Data After Shutdown |
| Compatible Accessories | Document Extenders, Feeder Consumables Kits, Imaging Guide Set, A3 Flatbed Accessory, Printer Accessory Kit and Switchable Background |
| Printer Consumables | Ink Cartridge and Carrier |
| Height | 34.79 cm (13.7 Inches) |
| Width | 48.9 cm (19.2 Inches) |
| Depth with Tray Closed | 46.73 cm (18.4 Inches) |
| Depth with Tray Open | 61.30 cm (24.1 Inches) |
| Weight | 30.4 kg (67 lb.) |
| Electrical Requirements | 100–240 V, 50–60 Hz |
| Running Power Consumption | Less Than 130 Watts |
| Sleep Power Consumption | Less Than 1.5 Watts |
| Standby Power Consumption | Less Than 0.5 Watts |
| Operating Temperature | 15–35°C (59–95°F) |
| Operating Humidity | 15%–80% RH |
| Environmental Certifications | ENERGY STAR, EPEAT Silver and 2008 EuP |
| Regional Certifications | Argentina S Mark, Australia/New Zealand RCM, Canada cTUVus and ICES-003, China CCC, European Union CE and GS Mark, India BIS, Japan VCCI, Mexico NOM, South Korea KC, Taiwan BSMI, US cTUVus and FCC |
Frequently Asked Questions (FAQs)
What is the scanning speed of the KODAK i4650?
The KODAK i4650 scans at speeds of up to 150 pages per minute and 300 images per minute.
How many sheets can the KODAK i4650 feeder hold?
The automatic document feeder can hold up to 500 sheets of 80 g/m² paper.
What is the recommended daily scanning volume?
The KODAK i4650 has a recommended daily volume of up to 130,000 pages.
What is Interactive Multifeed Recovery?
Interactive Multifeed Recovery allows the operator to review a detected multifeed and choose whether to accept, ignore or rescan the affected image before it is transferred to the connected application.
Can the KODAK i4650 detect staples and paper clips?
Yes. Its metal-detection system can identify staples, paper clips and other metallic objects that could damage documents or interrupt scanning.
Does the KODAK i4650 support long documents?
Yes. It supports documents measuring up to 305 mm wide and 9.1 metres long. A manually selected rear straight-through paper path is also available.
Does the KODAK i4650 support document imprinting?
Yes. Digital and physical imprinting options are available for workflows requiring document identification, tracking or reference information.
Which connectivity and drivers are supported?
The scanner uses USB 3.2 Gen 1×1 connectivity. It supports ISIS, TWAIN and WIA drivers, Linux TWAIN and SANE, and is KOFAX certified.
