KODAK S3120 Max A3 Production Scanner 120ppm 240ipm 500-Sheet ADF USB Ethernet
- 120ppm / 240ipm High-Speed A3 Scanning
- 500-Sheet ADF with Straight-Through Paper Path
- USB 3.2 & Gigabit Ethernet Connectivity
- 600dpi Optical Resolution with SurePath Intelligent Feed Technology
KODAK S3120 Max A3 Production Scanner 120ppm 240ipm 500-Sheet ADF
Product Features
The KODAK S3120 Max is a high-speed A3 production scanner designed for organizations that require productive, high-capacity document scanning. With scanning speeds of up to 120 pages per minute and 240 images per minute, it is suitable for demanding document digitization environments.
The 500-sheet automatic document feeder supports large scanning batches, while the straight-through paper path allows thick or exceptionally long documents to pass through the scanner efficiently.
SurePath intelligent document feed technology helps provide reliable document handling for high-volume scanning workflows. Continuous cropping mode also supports scanning documents of unlimited length.
The scanner provides up to 600 dpi optical resolution and image output up to 1200 dpi. Dual RGB LED illumination CIS technology supports grayscale and color image capture for a range of document digitization requirements.
USB 3.2 Gen 1×1 and 10/100/1000 Ethernet connectivity provide flexible options for connecting the scanner to computers and network environments. DHCP or static IP configuration and TCP/IP support enable network deployment.
A 3.5-inch graphical color touchscreen LCD with operator control buttons provides convenient control during scanning operations. The scanner also includes Capture Pro Limited Edition and Smart Touch software, with additional software options available.
With support for FADGI 2023 Modern Textual Records requirements, extensive barcode recognition, multiple scanning drivers, and compatibility with Windows and Linux operating systems, the KODAK S3120 Max is designed for professional document scanning and archival workflows.
Technical Specifications
| Brand | KODAK |
| Model | S3120 Max |
| Scanner Type | A3 High-Speed Production Scanner |
| Throughput Speed | 120 ppm / 240 ipm |
| Recommended Daily Volume | Up to 100,000 pages per day |
| ADF Capacity | Up to 500 sheets of 80 g/m² paper |
| Maximum Document Size | 305 mm × 4.06 m |
| Minimum Document Size | 63.5 mm × 71.1 mm |
| Continuous Cropping | Unlimited-Length Documents |
| Paper Thickness & Weight | 27–433 g/m² |
| Optical Resolution | 600 dpi |
| Output Resolution | Up to 1200 dpi |
| Scanning Technology | Dual RGB LED Illumination CIS (CMOS) |
| Grayscale | 8-bit |
| Color Output | 24-bit |
| Color Capture | 48-bit |
| Connectivity | USB 2.0 Compatible, USB 3.2 Gen 1×1, 10/100/1000 Ethernet |
| Network Protocols | DHCP / Static IP, TCP/IP |
| Operator Panel | 3.5-inch Graphical Color Touchscreen LCD |
| Quick Scan Jobs | 20 |
| Bundled Software | Capture Pro Limited Edition, Smart Touch |
| Optional Software | Capture Pro Software, Info Input Solution |
| Supported Barcodes | Codabar, Code 128, Code 3 of 9, EAN-13, EAN-8, Interleaved 2 of 5, PDF417, QR, UPC-A, UPC-E |
| Dimensions | 457.2 × 370.8 × 295 mm |
| Weight | 16.8 kg |
| Power Requirements | 100–240 V, 50–60 Hz |
| Power Consumption | <50 W Running, <4 W Sleep, <0.3 W Standby |
| Operating Conditions | 10–35°C, 15%–80% RH |
| Acoustical Noise | <20 dB(A) Ready, <60 dB(A) Scanning |
| Data Security | Scanned data processed through volatile memory |
| Archival Compliance | FADGI 2023 Modern Textual Records |
| Environmental Certifications | ENERGY STAR Qualified, EPEAT Gold, 2008 EuP |
Frequently Asked Questions (FAQs)
What is the scanning speed of the KODAK S3120 Max?
The KODAK S3120 Max scans at speeds of up to 120 pages per minute or 240 images per minute.
How many sheets can the ADF hold?
The automatic document feeder can accommodate up to 500 sheets of 80 g/m² paper.
Does the KODAK S3120 Max support A3 documents?
Yes, the scanner supports documents up to 305 mm wide and documents up to 4.06 meters long.
Does the scanner support network connectivity?
Yes, it supports 10/100/1000 Ethernet as well as USB 3.2 Gen 1×1 connectivity.
What optical resolution does the S3120 Max provide?
It provides a maximum optical resolution of 600 dpi and image output resolution of up to 1200 dpi.
What software is included with the scanner?
The scanner includes Capture Pro Limited Edition and Smart Touch software. Capture Pro Software and Info Input Solution are available as optional software.
