Intel Core i9-13900K 13th Gen 24-Core 32-Thread LGA1700 Unlocked Desktop Processor
- 13th Gen Intel Core i9 Processor with 24 Cores & 32 Threads
- Up to 5.80GHz Max Turbo Frequency with 36MB Intel Smart Cache
- Unlocked K-Series CPU with DDR5-5600 / DDR4-3200 & PCIe 5.0 Support
- Integrated Intel UHD Graphics 770 with LGA1700 Socket
Intel Core i9-13900K 13th Gen Desktop Processor
High-End 13th Generation Intel Core i9 Processor
The Intel Core i9-13900K is a high-performance 13th Generation desktop processor based on Intel’s Raptor Lake architecture. It combines 8 Performance-cores and 16 Efficient-cores for a total of 24 cores and 32 threads, delivering exceptional performance for gaming, content creation, rendering, streaming and demanding professional workloads.
With a maximum turbo frequency of up to 5.80GHz, 36MB Intel Smart Cache, 32MB L2 cache, support for DDR5 and DDR4 memory, PCIe 5.0 connectivity and integrated Intel UHD Graphics 770, the Core i9-13900K provides a powerful foundation for premium LGA1700 desktop systems.
Product Features
24-Core Hybrid Architecture: Combines 8 Performance-cores with 16 Efficient-cores for a total of 24 physical cores.
32 Processing Threads: Intel Hyper-Threading support provides up to 32 threads for gaming, multitasking and heavily multi-threaded professional workloads.
Up to 5.80GHz Turbo: Intel Thermal Velocity Boost allows the processor to reach frequencies of up to 5.80GHz when thermal and power conditions permit.
Turbo Boost Max Technology 3.0: Selected high-performing cores can reach up to 5.70GHz with Intel Turbo Boost Max Technology 3.0.
Performance-Core Speeds: Performance-cores operate at a 3.00GHz base frequency and can boost up to 5.40GHz.
Efficient-Core Speeds: Efficient-cores operate at a 2.20GHz base frequency and can boost up to 4.30GHz.
Unlocked K-Series Processor: The Core i9-13900K features an unlocked multiplier for supported CPU tuning and overclocking with compatible hardware.
36MB Intel Smart Cache: A large shared cache helps improve responsiveness and data access across demanding gaming and professional applications.
32MB L2 Cache: Additional L2 cache contributes to strong multi-core and multi-threaded performance.
DDR5 & DDR4 Support: Supports up to DDR5-5600 and DDR4-3200 memory, providing flexibility when selecting a compatible LGA1700 motherboard.
Dual-Channel Memory: Supports two memory channels with maximum memory bandwidth up to 89.6GB/s.
Up to 192GB Memory: Supports memory capacities up to 192GB depending on the motherboard, BIOS and installed memory configuration.
ECC Memory Support: ECC memory is supported when used with a compatible motherboard platform and memory configuration.
PCIe 5.0 & 4.0: Supports PCI Express 5.0 and PCIe 4.0 with up to 20 processor PCIe lanes for compatible graphics cards and storage hardware.
Intel UHD Graphics 770: Integrated graphics provide display functionality without requiring a dedicated graphics card for supported workloads.
Intel Quick Sync Video: Hardware-accelerated media processing can improve supported encoding, transcoding and streaming workflows.
Intel Adaptive Boost Technology: Allows supported cores to operate at higher frequencies when thermal and power conditions permit.
Intel Thread Director: Helps supported operating systems assign workloads efficiently between Performance-cores and Efficient-cores.
125W Processor Base Power: The Core i9-13900K has a processor base power of 125W and maximum turbo power of up to 253W.
LGA1700 Socket: Designed for compatible Intel 600-series and 700-series motherboards with suitable chipset and BIOS support.
Product Specifications
| Brand | Intel |
| Series | Intel Core i9 |
| Model | Core i9-13900K |
| Generation | 13th Generation |
| Code Name | Raptor Lake |
| Socket | FCLGA1700 |
| Lithography | Intel 7 |
| Unlocked | Yes |
| Total Cores | 24 |
| Performance Cores | 8 |
| Efficient Cores | 16 |
| Total Threads | 32 |
| Max Turbo Frequency | Up to 5.80GHz |
| Thermal Velocity Boost | 5.80GHz |
| Turbo Boost Max 3.0 | 5.70GHz |
| P-Core Max Turbo | 5.40GHz |
| E-Core Max Turbo | 4.30GHz |
| P-Core Base Frequency | 3.00GHz |
| E-Core Base Frequency | 2.20GHz |
| Intel Smart Cache | 36MB |
| Total L2 Cache | 32MB |
| Processor Base Power | 125W |
| Maximum Turbo Power | 253W |
| Maximum Memory | Up to 192GB* |
| Memory Support | DDR5-5600 / DDR4-3200 |
| Memory Channels | 2 |
| Maximum Memory Bandwidth | 89.6GB/s |
| ECC Memory | Supported* |
| Integrated Graphics | Intel UHD Graphics 770 |
| Graphics Base Frequency | 300MHz |
| Graphics Max Dynamic Frequency | 1.65GHz |
| Graphics Execution Units | 32 |
| Maximum Displays | Up to 4 |
| PCI Express | PCIe 5.0 / PCIe 4.0 |
| Maximum PCIe Lanes | 20 |
| DMI Revision | 4.0 |
| Maximum DMI Lanes | 8 |
| TJUNCTION | 100°C |
| Intel Thermal Velocity Boost | Yes |
| Intel Adaptive Boost Technology | Yes |
| Intel Turbo Boost Max 3.0 | Yes |
| Intel Thread Director | Yes |
| Intel Hyper-Threading | Yes |
| Intel Quick Sync Video | Yes |
| Virtualization | Intel VT-x / VT-d Supported |
| Instruction Set | 64-bit |
*Maximum memory capacity, ECC support and available features depend on the motherboard chipset, BIOS version and system configuration.
24 Cores and 32 Threads
The Intel Core i9-13900K combines eight Performance-cores and sixteen Efficient-cores for a total of 24 cores and 32 threads. This configuration is designed for demanding gaming while also delivering substantial multi-threaded performance for editing, rendering, streaming, compiling and professional workloads.
Up to 5.80GHz with Thermal Velocity Boost
Intel Thermal Velocity Boost allows the processor to reach up to 5.80GHz when operating conditions permit. Intel Turbo Boost Max Technology 3.0 can also boost selected cores up to 5.70GHz for applications that benefit from strong single-threaded performance.
Unlocked for Performance Tuning
As a K-series processor, the Core i9-13900K features an unlocked multiplier. Supported overclocking requires a compatible motherboard chipset, suitable BIOS configuration, capable power delivery and adequate cooling.
DDR5-5600 and DDR4-3200 Support
Support for both DDR5-5600 and DDR4-3200 gives system builders flexibility when selecting a motherboard. DDR5 provides higher official memory bandwidth, while DDR4 allows compatible value-focused or existing configurations.
Intel UHD Graphics 770
Integrated Intel UHD Graphics 770 provides display output without requiring a dedicated graphics card. It also supports Intel Quick Sync Video and up to four displays depending on motherboard connectivity and system configuration.
PCIe 5.0 Connectivity
Support for PCI Express 5.0 and PCIe 4.0 provides high-bandwidth connectivity for compatible graphics cards and storage devices. The processor supports up to 20 PCIe lanes.
High-Performance Cooling Requirements
The Core i9-13900K has a 125W processor base power and can reach up to 253W maximum turbo power. A high-performance CPU cooling solution and motherboard with suitable power delivery are recommended for sustained workloads.
Important Compatibility Information
The Intel Core i9-13900K requires a compatible LGA1700 motherboard. Some Intel 600-series motherboards may require an appropriate BIOS update before supporting 13th Generation processors.
Memory speed, ECC support, integrated graphics outputs, PCIe functionality and overclocking capability depend on the selected motherboard and overall system configuration.
