Avision AD3100WN Wireless Network Document Scanner
- Scanning Speed: Up to 100 ppm / 200 ipm in color and black and white at 200–300 dpi.
- Feeder Capacity: 100-sheet automatic document feeder for A4, 80 g/m² paper.
- Daily Volume: Recommended for up to 15,000 pages per day.
- Connectivity: Wi-Fi, Ethernet and USB 3.2 Gen 1×1.
- Resolution: 600 × 600 dpi optical resolution with output up to 1200 × 1200 dpi.
- Document Handling: Supports legal-size documents and embossed cards up to 1.25 mm thick.
- Paper Detection: Ultrasonic paper jam detection.
- Compact Design: Weighs 4.7 kg for practical desktop placement.
Avision AD3100WN Wireless Network Document Scanner
The Avision AD3100WN Scanner brings Wi-Fi, Ethernet and USB connectivity to high-speed document capture. For businesses in Pakistan processing invoices, forms and office records, it combines flexible connection options with a 100-sheet automatic document feeder and duplex scanning.
100 ppm Scanning at 200 and 300 dpi
Scan A4 portrait documents at up to 100 pages per minute or 200 images per minute in duplex mode. These speeds apply to both color and black-and-white scanning at 200 and 300 dpi. The recommended daily volume of up to 15,000 pages supports busy departments handling regular batches of paperwork.
Wi-Fi, Ethernet and Direct USB Connection
Built-in Wi-Fi and Ethernet provide wireless and wired network connection options, while USB 3.2 Gen 1×1 supports direct connection to a compatible computer. Listed software includes Virtual Scanner Link for use within a supported scanning setup. Connection and software requirements should be checked for the intended operating system.
Flexible Paper and Card Handling
The ADF holds up to 100 sheets of A4, 80 g/m² paper and supports standard document sizes from 50 × 50 mm to 216 × 356 mm. Paper weights from 27 to 413 g/m² and embossed cards up to 1.25 mm thick are supported. Long paper mode accommodates extended documents at selected resolutions.
Detailed Images and Document Capture Software
Capture documents at 600 × 600 dpi optical resolution, with output available up to 1200 × 1200 dpi. Ultrasonic paper jam detection helps identify feeding problems. Button Manager, PaperPort and AVScan are listed alongside TWAIN, ISIS and WIA drivers. Available output formats and software functionality depend on the application and operating system used.
Technical Specifications
| Brand | Avision |
|---|---|
| Model | AD3100WN |
| Scanner Type | Wireless network sheet-fed document scanner with ADF |
| Scanning Modes | Simplex and duplex |
| Scanning Technology | CMOS-CIS |
| Light Source | LED |
| Memory | 512 MB SDRAM |
| Black and White Speed | Up to 100 ppm simplex / 200 ipm duplex at 200 or 300 dpi |
| Color Speed | Up to 100 ppm simplex / 200 ipm duplex at 200 or 300 dpi |
| Recommended Daily Volume | Up to 15,000 pages |
| ADF Capacity | Up to 100 sheets of A4, 80 g/m² paper |
| Optical Resolution | 600 × 600 dpi |
| Output Resolution | Up to 1200 × 1200 dpi |
| Minimum ADF Document Size | 50 × 50 mm |
| Maximum Standard ADF Scan Size | 216 × 356 mm (Legal; 8.5 × 14 inches) |
| ADF Paper Width Accommodation | Up to 242 mm; listed maximum standard scanning width is 216 mm |
| Long Paper Mode | Color duplex: up to 6096 mm at up to 200 dpi; 5540 mm at up to 300 dpi; 1500 mm at up to 600 dpi |
| Paper Weight | 27–413 g/m² |
| Card Scanning | Embossed cards up to 1.25 mm thick |
| Ultrasonic Paper Jam Detection | Yes |
| Halftone Patterns | Dither and error diffusion |
| Grayscale Mode | 16-bit input / 8-bit output |
| Color Mode | 48-bit input / 24-bit output |
| File Formats | BMP, PNG, GIF, JPEG, single-page PDF, multi-page PDF, Multi-TIFF, TIFF, RTF, TXT, XPS, DOC, XLS, PPT, DOCX, XLSX, PPTX and HTML; OCR listed for iScan only |
| USB Interface | USB 3.2 Gen 1×1 |
| Wireless Connectivity | Wi-Fi |
| Ethernet Port | RJ-45 Ethernet, listed at 10/100/1000 Mbps |
| Bundled Software and Drivers | TWAIN Driver, ISIS Driver, WIA Driver, Button Manager, PaperPort, AVScan and Virtual Scanner Link |
| Windows Support | Windows 7, 8, 10 and 11; Windows Server 2008 R2, 2012, 2016, 2019, 2022 and 2025 |
| Linux Support | Fedora, openSUSE, Debian and Ubuntu |
| macOS Support | macOS 10.12 through macOS 14 Sonoma |
| Maximum Dimensions (W × D × H) | 316 × 680 × 239 mm |
| Minimum Dimensions (W × D × H) | 316 × 191 × 168 mm |
| Weight | 4.7 kg |
| Power Consumption | Operation: <60W; ready: <15W; sleep: <2.9W; off: <0.3W |
| Acoustical Noise | Operation: <63 dB; ready: <45 dB |
Avision AD3100WN Scanner Price in Pakistan
Contact Tescom Engineering for the latest Avision AD3100WN Scanner price in Pakistan, current availability and ordering details.
