Intel Core i7-14700F 14th Gen 20-Core 28-Thread LGA1700 Desktop Processor
- 14th Gen Intel Core i7 Processor with 20 Cores & 28 Threads
- Up to 5.40GHz Max Turbo Frequency with 33MB Intel Smart Cache
- Supports DDR5-5600 & DDR4-3200 Memory with PCIe 5.0 / 4.0
- F-Series Processor with No Integrated Graphics – Dedicated GPU Required
Intel Core i7-14700F 14th Gen Desktop Processor
High-Performance 14th Generation Intel Core i7 Processor
The Intel Core i7-14700F is a 14th Generation desktop processor designed for demanding gaming, productivity, content creation and professional workloads. It combines 8 Performance-cores and 12 Efficient-cores for a total of 20 cores and 28 threads, providing strong single-core performance together with substantial multi-threaded capability.
With a maximum turbo frequency of up to 5.40GHz, 33MB Intel Smart Cache, support for DDR5 and DDR4 memory, and PCIe 5.0 connectivity, the Core i7-14700F is a powerful choice for compatible LGA1700 desktop systems equipped with a dedicated graphics card.
Product Features
20-Core Hybrid Architecture: Combines 8 Performance-cores and 12 Efficient-cores for a total of 20 physical cores.
28 Processing Threads: Intel Hyper-Threading support provides up to 28 threads for gaming, rendering, editing, streaming and heavy multitasking.
Up to 5.40GHz Turbo: Intel Turbo Boost Max Technology 3.0 allows selected cores to reach up to 5.40GHz when thermal and power conditions permit.
Performance-Core Speeds: Performance-cores operate at a 2.10GHz base frequency and can boost up to 5.30GHz.
Efficient-Core Speeds: Efficient-cores operate at a 1.50GHz base frequency and can boost up to 4.20GHz.
33MB Intel Smart Cache: A large shared cache helps improve data access and responsiveness across demanding applications.
28MB L2 Cache: Additional L2 cache contributes to strong multi-core and multi-threaded performance.
DDR5 & DDR4 Support: Supports up to DDR5-5600 and DDR4-3200 memory, providing flexibility when choosing a compatible LGA1700 motherboard.
Dual-Channel Memory: Supports two memory channels with maximum memory bandwidth up to 89.6GB/s.
Up to 192GB Memory: Supports system memory capacities up to 192GB depending on the motherboard, BIOS and memory configuration.
PCIe 5.0 & 4.0: Supports PCI Express 5.0 and PCIe 4.0 with up to 20 processor PCIe lanes for compatible graphics cards and storage devices.
No Integrated Graphics: The Core i7-14700F is an F-series processor and does not include active integrated graphics. A compatible dedicated graphics card is required for display output.
Intel Thread Director: Helps supported operating systems assign workloads efficiently between Performance-cores and Efficient-cores.
Intel Turbo Boost Technology 2.0: Dynamically increases processor frequency when additional performance is required and operating conditions allow.
65W Processor Base Power: The processor has a base power rating of 65W and can reach up to 219W maximum turbo power.
LGA1700 Socket: Designed for compatible Intel 600-series and 700-series motherboards with suitable chipset and BIOS support.
Product Specifications
| Brand | Intel |
| Series | Intel Core i7 |
| Model | Core i7-14700F |
| Generation | 14th Generation |
| Code Name | Raptor Lake |
| Segment | Desktop |
| Socket | FCLGA1700 |
| Lithography | Intel 7 |
| Total Cores | 20 |
| Performance Cores | 8 |
| Efficient Cores | 12 |
| Total Threads | 28 |
| Max Turbo Frequency | Up to 5.40GHz |
| Turbo Boost Max 3.0 Frequency | 5.40GHz |
| P-Core Max Turbo | 5.30GHz |
| E-Core Max Turbo | 4.20GHz |
| P-Core Base Frequency | 2.10GHz |
| E-Core Base Frequency | 1.50GHz |
| Intel Smart Cache | 33MB |
| Total L2 Cache | 28MB |
| Processor Base Power | 65W |
| Maximum Turbo Power | 219W |
| Maximum Memory | Up to 192GB* |
| Memory Support | DDR5-5600 / DDR4-3200 |
| Memory Channels | 2 |
| Maximum Memory Bandwidth | 89.6GB/s |
| Integrated Graphics | No |
| Dedicated GPU Required | Yes |
| PCI Express | PCIe 5.0 / PCIe 4.0 |
| Maximum PCIe Lanes | 20 |
| DMI Revision | 4.0 |
| Maximum DMI Lanes | 8 |
| TJUNCTION | 100°C |
| Maximum Operating Temperature | 100°C |
| Intel Thread Director | Yes |
| Intel Turbo Boost Max 3.0 | Yes |
| Intel Turbo Boost Technology | 2.0 |
| Intel Hyper-Threading | Yes |
| Virtualization | Intel VT-x / VT-d Supported |
| Instruction Set | 64-bit |
*Maximum memory capacity and available features depend on the motherboard chipset, BIOS version and memory configuration.
20 Cores and 28 Threads
The Intel Core i7-14700F combines eight Performance-cores and twelve Efficient-cores for a total of 20 cores and 28 threads. This configuration provides strong gaming performance while also delivering substantial multi-threaded capability for editing, rendering, streaming and professional applications.
Up to 5.40GHz Turbo Performance
Intel Turbo Boost Max Technology 3.0 allows selected cores to reach up to 5.40GHz when thermal and power conditions permit, helping deliver responsive performance in applications that benefit from high single-core frequencies.
DDR5-5600 and DDR4-3200 Support
The processor supports both DDR5-5600 and DDR4-3200 memory, allowing system builders to choose between newer high-bandwidth DDR5 platforms and compatible DDR4 motherboard configurations.
PCIe 5.0 Connectivity
Support for PCI Express 5.0 and PCIe 4.0 provides modern high-bandwidth connectivity for compatible dedicated graphics cards and storage hardware. The processor supports up to 20 PCIe lanes.
Dedicated Graphics Card Required
The Core i7-14700F is an F-series Intel processor and does not provide active integrated graphics. A compatible dedicated graphics card is therefore required to connect a monitor and obtain display output.
65W Base Power with High Turbo Capability
The Core i7-14700F has a 65W processor base power but can reach up to 219W maximum turbo power. A capable motherboard power design and suitable CPU cooling solution are recommended for sustained high-performance workloads.
Important Compatibility Information
The Intel Core i7-14700F requires a compatible LGA1700 motherboard. Intel 600-series and 700-series motherboards may require an appropriate BIOS version before supporting 14th Generation processors.
Memory speed and PCIe functionality depend on the selected motherboard and overall system configuration. A dedicated graphics card is required because the Core i7-14700F has no integrated graphics.
